Server DELL PowerEdge R320
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
- Chassis
- 1U rack
- Processors
- Intel Xeon processor E5-2400 product family
Intel Xeon processor E5- 1410
Intel Pentium processor 1400 product family - Processor socket
- 1 socket
- Front side bus
- Intel DMI 2.0
- Cache
- 2.5MB per core with core options of 2, 4, 6, or 8
- Chipset
- Intel C600
- Memory
- Up to 192GB (6 DIMM slots): 2GB/4GB/8GB/16GB/32GB DDR3 up to 1600MT/s
- PCIe slots
- 2 PCIe slots
• 1 x8 slot with x4 bandwidth, 2.0, half-height, half-length
• 1 x16 slot with x16 bandwidth, 3.0, full-height, half-length - RAID controller
- Internal controllers:
PERC S110 (SW RAID)
PERC H310
PERC H710
External HBAs (RAID):
PERC H810
External HBAs (non-RAID):
6Gbps SAS HBA - Hard drives
- Drive bay options:
4 x 3.5” cabled SAS or SATA drives or
4 x 3.5” hot-plug SAS, SATA or SSD drives (2.5” hybrid kit available) or
8 x 2.5” hot-plug SAS, SATA or SSD drives
Hot-plug hard drive options:
2.5” SATA, nearline SAS, SAS (15K, 10K), SAS SSD, SATA SSD
3.5” SATA, nearline SAS, SAS (15K)
Self-encrypting drives available
Cabled hard drive options:
3.5” SATA, nearline SAS, SAS (15K) - Embedded NIC
- Broadcom® 5720 Dual Port 1GbE LO
- I/O adapter options
- 1Gb Ethernet:
Broadcom 5720 Dual Port 1Gb NIC
Broadcom 5719 Quad Port 1Gb NIC
Intel I350 Dual Port 1Gb stand-up adapter
Intel I350 Quad Port 1Gb stand-up adapter
10Gb Converged Ethernet:
Brocade® BR1020 Dual Port 10Gb CNA
QLogic® QLE8262 Dual Port 10Gb DA/SFP+
Broadcom 57810S Dual Port 10Gb Base-T CNA
Broadcom 57810S Dual Port 10Gb DA/SFP+ CNA
10Gb Ethernet:
Intel X520 Dual Port 10Gb DA/SFP+ server adapter
Intel X540 Dual Port 10Gb Base-T adapter
FC8/FC4 HBA:
QLogic QLE2460 4Gb Single Port FC HBA
QLogic QLE2462 4Gb Dual Port FC HBA
QLogic QLE2560 8Gb Single Port FC HBA
QLogic QLE2562 8Gb Dual Port FC HBA
Emulex® LPe- 12000- E 8Gb Single Port FC HBA
Emulex LPe- 12002- E 8Gb Dual Port FC HBA
Brocade 815 8Gb Single Port FC HBA
Brocade 825 8Gb Dual Port FC HBA - Power supply
- Platinum efficiency 350W or 550W power supply Bronze efficiency cabled 350W power supply Auto-ranging power supplies
- Availability
- High-efficiency, hot-plug, redundant power supplies; hot-plug hard drives; TPM/No-TPM; dual internal SD support; optional bezel; information tag; ECC memory; interactive LCD screen; extended power range; ENERGY STAR® compliant
- Dell OpenManage Systems Management (Agent-free or with OpenManage Server Administrator [OMSA] Agent)
- OpenManage Essentials
• Dell Management Console
• IT Assistant
• OMSA Agent
• OpenManage Power Center (requires iDRAC7 Enterprise with Lifecycle
Controller)
• OpenManage Integrations and Connections:
- OpenManage Integration Suite for Microsoft® System Center
- Dell Management Plug-in for VMware vCenter™
- Connections for HP® Operations Manager, IBM® Tivoli® Netcool® and CA
Network and Systems Management
• Basic management (standard option)
- Upgrade to iDRAC7 (Express or Enterprise) with Lifecycle Controller
- Upgrade to 8GB vFlash media or 16GB vFlash media for iDRAC7 Enterprise
with Lifecycle Controller
- Trial evaluations available for IDRAC7 (Express and Enterprise) with Lifecycle
Controller - Rack support
- • ReadyRailsTM II sliding rails for tool-less mounting in 4-post racks with square or
unthreaded round holes or tooled mounting in 4-post threaded hole racks, with
support for optional tool-less cable management arm
• ReadyRails static rails for tool-less mounting in 4-post racks with square or
unthreaded round holes or tooled mounting in 4-post threaded and 2-post
(Telco) racks - Operating systems
- Microsoft® Windows Server® 2012
Microsoft Windows Server 2012 Essentials
Microsoft Windows Server 2008 R2 SP1, x64 (includes Hyper-V® v2)
Microsoft Windows® Small Business Server 2011
Novell® SUSE® Linux Enterprise Server
Red Hat® Enterprise Linux®
Virtualization options:
Citrix® XenServer®
VMware vSphere including ESX™ and ESXi™
Red Hat Enterprise Virtualization®
Dell PowerEdge R320 Review
The Dell PowerEdge R320 is an enterprise-class, 1-socket, 1U rack-mount server designed to deliver the right combination of performance, redundancy and value in a dense chassis. This rack server caters to the growing need for virtualization by offering scalable processor performance, a large memory footprint and the capacity for up to eight hard drives. The performance per cost, along with configuration flexibility, storage connectivity and straightforward systems management make the R320 highly appealing to hosting providers. Consistent worldwide support makes the R320 highly appealing to multinational businesses and organizations.
Enterprise features, scalable expandability and value in a dense chassis
The R320 features the scalable performance of the Intel® Xeon® E5-2400 processors with essential Intel memory RAS features. This server complements its processors with six DIMMs and two PCI Express® (PCIe) slots, providing a substantial memory footprint and wide I/O bandwidth to support both memory-sensitive applications and databases. These combined technology features enable the R320 to support consolidated and virtualized environments. To protect your virtualized workloads, the R320 offers dual SD cards making your hypervisors redundant and failsafe. Other reliability and availability features include up to four 3.5-inch or eight 2.5-inch hot-plug hard drives, both hardware and software RAID options and redundant, hot-plug power supplies.
Ideal for your applications
The R320 is an excellent fit for web, file and print serving as well as smaller scale hosting and e-commerce, retail server, workgroup server and smaller scale virtualization in space-constrained, small-medium business locations and departmental and remote sites of large businesses and public organizations.
Enterprise-class network options
As a 1-socket rack server, the R320 has very aggressive advanced network options, carrying multiple third-party brands and adapter types with 10GbE NIC, 10GbE FCoE and Fiber Channel 8Gb HBA.
The PowerEdge server line
The PowerEdge family is engineered with the right combination of features and performance scalability to handle tough workloads for both large and small data center environments. The Dell OpenManage™ systems management portfolio includes integrated Dell Remote Access Controller (iDRAC) with Lifecycle Controller. This embedded feature helps IT administrators manage Dell servers in physical, virtual, local and remote environments, operating in-band or out-of-band, with or without a systems management software agent. OpenManage integrates and connects to third-party systems management solutions so you can maintain your single point of control and capitalize on your existing investment. OpenManage simplifies the lifecycle of deploying, updating, monitoring, and maintaining your Dell PowerEdge servers.
