Processor
1 or 2 x 4th or 5th Generation AMD EPYC™ 9004/9005 Series processors, up to 160 cores depending on processor, up to 5.0 GHz, up to 1152 MB L3 cache
Memory
DDR5 RDIMM: up to 24 x HPE DDR5 Smart Memory DIMMs (6 TB), speeds up to 6400 MT/s depending on processor and population
Storage controllers
- HPE Tri-Mode storage controllers for SAS/SATA/NVMe configurations
Drive bays
Front drive support
- Up to 8 x SFF SAS/SATA/NVMe drives
- Up to 8+2 x SFF SAS/SATA or NVMe drives depending on configuration
- Up to 20 x EDSFF E3.S NVMe drives
Power supplies
- 500 W Flex Slot Platinum
- 800 W Flex Slot Platinum
- 1600 W Flex Slot Platinum
Cooling and fans
Air cooling or Direct Liquid Cooling; 5 fans included, high-performance fan options depending on configuration
Dimensions
- Height: 42.9 mm (1.69 inches)
- Width: 448.9 mm (17.67 inches)
- Depth: up to 708.9 mm (27.91 inches)
- Weight: up to 19.00 kg (41.89 lb)
Form factor
1U rack server
Embedded management
- HPE iLO 6 Standard with Intelligent Provisioning
- HPE OneView Standard
- HPE iLO Advanced, optional
- HPE OneView Advanced, optional
- HPE Compute Ops Management
- Redfish API support
Security
- UEFI Secure Boot and Secure Start
- Immutable Silicon Root of Trust
- AMD Secure Processor integration for secure boot, memory encryption and secure virtualization
- IDevID certificates installed by default
- Secure Recovery with restoration of validated firmware
- Optional iLO security modes, TPM, chassis intrusion detection and bezel locking kits
Networking
- Optional OCP and PCIe network adapters depending on model
- Wide range of speeds, cabling and chipsets
Ports
Front ports
- 1 x iLO Service Port
- 1 x USB 3.2 Gen1
- 1 x USB 2.0, optional
- 1 x DisplayPort, optional
Internal ports
- 1 x USB 3.2 Gen1
- 1 x USB 2.0
Rear ports
- 1 x dedicated 1GbE iLO Management Port
- 2 x USB 3.2 Gen1
- 1 x VGA
- 1 x Serial port, optional
PCIe expansion
Up to 2 x PCIe Gen5 slots and up to 2 x OCP slots
Optical drive
Optional 9.5 mm SATA DVD-ROM/RW optical drive
Operating systems and virtualization
- Microsoft Windows Server 2019, 2022, 2025
- VMware ESXi 7.0 U3; VMware ESXi 8.0, 8.0 U1, 8.0 U2, 8.0 U3; VMware ESX 9.0, 9.1
- Red Hat Enterprise Linux 8.6, 9.0, 10.0; AMD EPYC™ 9005 configurations require RHEL 8.10 or RHEL 9.4 minimum
- SUSE Linux Enterprise Server 15 SP4 and SLE Micro 5.3 for AMD EPYC™ 9004; SLES 16, SLES 15 SP5, SL Micro 6.2 and SLE Micro 5.5 for AMD EPYC™ 9005
- Canonical Ubuntu 20.04.5 LTS, 22.04 LTS, 24.04 LTS; AMD EPYC™ 9005 configurations require Ubuntu 22.04.5 LTS with 6.8.0 kernel minimum
- Oracle Linux 9.2 for AMD EPYC™ 9004; Oracle Linux 9.4 or 10.0 for AMD EPYC™ 9005
- Condition
- New
- Manufacturer
- HPE
- Form factor
- 1U
- Remote-Control-Modul
- iLO 6 Standard
- Supported RAM
- DDR5 DIMM 24 slots (6144 GB)
- Power supply unit
- 1 × HP 800W
- RAID controller
- RAID HPE MR216i-o
- HDD bays
- noHDD (up to Array HDD 2.5'' SFF)
- NIC card
- 4 ports 1GB Base-T RJ-45 PCI-e
Need a technical consultation on choosing a server?
Submit a requestHPE ProLiant DL365 Gen11 8SFF is a storage configuration with eight front-accessible 2.5-inch SFF drive bays for a dense 1U dual-socket AMD rack platform. It is designed for hybrid cloud, virtualization, databases, VDI, and application infrastructure that requires dense compute and flexible local storage.
Key features:
-
8 front SFF bays: Eight front-accessible 2.5-inch bays provide dense local storage in a compact chassis and support fast servicing of validated hot-plug drives.
-
U.3 Tri-Mode drive support: Supported U.3 Tri-Mode backplanes can carry SAS, SATA, and U.3 NVMe drives. The exact drive set depends on the selected backplane, controller or direct-attach path, cabling, firmware, and HPE configuration rules.
-
Validated Tri-Mode controller paths: HPE MR and SR Gen11 controller options can provide hardware RAID for supported SAS, SATA, and U.3 NVMe media. Direct-attach capabilities vary by backplane, so the controller and cable selection must follow the server QuickSpecs.
-
Optional expansion to 10 SFF: An additional 2SFF U.3 cage can raise the front drive count from eight to ten. This option can replace the optical-media choice and requires the correct backplane, controller or direct-attach path, and cooling selection.
-
Dense 1U dual-socket AMD platform: Fourth- and fifth-generation AMD EPYC processors, DDR5 memory, PCIe Gen5 I/O, and HPE iLO 6 provide high compute density for virtualization, VDI, and technical workloads.
Use cases:
-
Virtualization: Provides serviceable local HDD or SSD storage for virtual machines, hypervisors, and consolidated infrastructure services.
-
VDI and user-computing services: Combines compute density with responsive local storage for virtual desktops, application delivery, and user-session infrastructure.
-
EDA, CAD, and technical computing: Fast SFF storage can support engineering datasets, build environments, and technical applications with demanding I/O patterns.
-
Private cloud infrastructure: Can be used for compact private-cloud nodes, orchestration services, and distributed enterprise compute pools.
HPE ProLiant DL365 Gen11 8SFF is a flexible SFF configuration for organizations that need HPE-validated SAS, SATA, or U.3 NVMe storage paths in a compact enterprise server.
