DELL PowerEdge R430 Server

Out of production
?

Ooops :( This server is out of stock. Contact manager to find something similar

Refubrished
from €258.–
Free 5-years ProSupport warranity
Free shipping across EU if order > 500€
Delivery outside EU? Please contact manager
Rent with purchase or leasing
Out of production
?

Ooops :( This server is out of stock. Contact manager to find something similar

from €258.–
Free 5-years ProSupport warranity
Rent with purchase or leasing
Free shipping across EU if order > 500€
Delivery outside EU? Please contact manager

Chassis

NUMBER OF CPUs

?

Note that the second CPU heatsink and fan are included in the price.

To start, select the number of CPUs to be installed.

CPU

Sort by:
  • Core
  • Frequency
  • Cache
  • Core
  • Frequency
  • Cache
€7
€17
€22
€27
€14
€62
€126
€14
€64
€48
€47
€68
€94
€111
€62
€48
€111
€31
€50
€60
€72
€44
€140
€268
€44
€144
€113
€111
€152
€204
€237
€140
€113
€237
€7
€17
€22
€27
€14
€62
€126
€14
€64
€48
€47
€68
€94
€111
€62
€48
€111
€31
€50
€60
€72
€44
€140
€268
€44
€144
€113
€111
€152
€204
€237
€140
€113
€237
€7
€17
€22
€27
€14
€62
€126
€14
€64
€48
€47
€68
€94
€111
€62
€48
€111
€31
€50
€60
€72
€44
€140
€268
€44
€144
€113
€111
€152
€204
€237
€140
€113
€237
Ram Total: 0 GB

If the number of CPUs is twin, the number of RAM stick should also be twin. Maximum total value is 1536GB.

€11
no more than 12 pcs.
no more than 1536 pcs.
+
-
€14
no more than 12 pcs.
no more than 1536 pcs.
+
-
€19
no more than 12 pcs.
no more than 1536 pcs.
+
-
€27
no more than 12 pcs.
no more than 1536 pcs.
+
-
€45
no more than 12 pcs.
no more than 1536 pcs.
+
-
€51
no more than 12 pcs.
no more than 1536 pcs.
+
-
€11
no more than 24 pcs.
only twin number
+
-
€14
no more than 24 pcs.
only twin number
+
-
€19
no more than 24 pcs.
only twin number
+
-
€27
no more than 24 pcs.
only twin number
+
-
€45
no more than 24 pcs.
only twin number
+
-
€51
no more than 24 pcs.
only twin number
+
-
RAID

€69
€165
included
Remote access controller

€54
included
Power supply unit

€35
€69
LAN adapter

included
€21
€370
€27
€69
OS

ask manager
ask manager
included
Rack rails

€69
HDD 8 BAY

By default, we do not include disks. You can choose any disk from the list below. Maximum quantity of disks is 8.

€73
+
-
€115
+
-
€210
+
-
€359
+
-
€704
+
-
ask manager
+
-
ask manager
+
-
ask manager
+
-
ask manager
+
-
Tray caddy options

€10
no more than 8 pcs.
+
-
Send configuration via email
Can't find the parts you need?
We’ll find a solution.
Contact us
Check the current prices with the manager
Out of production
?

Ooops :( This server is out of stock. Contact manager to find something similar

### ###.—
Free 5-years ProSupport warranty
Free shipping across EU countries
if your order is more than 500€
Free shipping across EU countries if order more than €500. Delivery cost outside of EU starts from €250. Please check it with our manager.
Free shipping across EU
Free 5-years ProSupport warranty
Rent-to-own or lease
Out of production

Your configuration Dell R430 8SFF

Condition
  • Refurbished
CPU
  • Intel Xeon E5-2609 4C 10M Cache, 2.40 GHz
RAM
Raid
Cash memory of RAID controller
Power supply unit
OS
Rack rails
  • 19''
HDD 25 Bay
PCI 25 Bay
Remote access controller
LAN adapter
Rent-to-own or lease

Analogs R430

HDD Type
Max quantity of HDD
1/1

DELL R430 Technical specifications

Get an offer in hour
Form factor 1U rack server
Dimensions and weight H: 42.8 mm (1.68 in)
W: 482.4 mm (18.99 in) with rack latches; 434.0 mm
(17.08 in) without rack latches
D: 607.0 mm (23.9 in) without bezel; 676.92 mm
(26.7 in) with bezel
Weight
16.73 kg (36.88 lb) empty
19.9 kg (43.87 lb) maximum
Processor Intel® Xeon® processor E5-2600 v4 product family
Processor sockets: 2
Chipset: C610
Internal interconnect: Up to 9.6GT/s
Cache: 2.5MB per core; core options: 4, 6, 8, 10, 12, 14, 16, 18, 20
Memory DDR4 DIMMs at up to 2400MT/s
12 DIMM slots: 4GB/8GB/16GB/32GB⁠
I/O slots 2 PCIe 3.0
Storage SAS, SATA, nearline SAS, SSD Multiple R430 chassis available:
• 10 x 2.5" hot-plug drives
• 8 x 2.5" hot-plug drives
• 4 x 3.5" hot-plug drives
• 4 x 3.5" cabled drives
RAID controllers Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P
External HBAs (RAID): PERC H830
Communications 4 x 1GbE LOM
Power supplies 450W, 550W PSU
Systems management Systems management:
IPMI 2.0 compliant;
Dell OpenManage Essentials; Dell OpenManage Mobile;
Dell OpenManage Power Center

Remote management:
iDRAC8 with Lifecycle Controller, iDRAC8 Express
(default), iDRAC8 Enterprise (upgrade) 8GB vFlash media
(upgrade), 16GB vFlash media (upgrade)

Dell OpenManage Integrations:
• Dell OpenManage Integration Suite for Microsoft®
System Center
• Dell OpenManage Integration for VMware® vCenter™

Dell OpenManage Connections:
• HP Operations Manager, IBM Tivoli® Netcool® and
CA Network and Systems Management
• Dell OpenManage Plug-in for Oracle® Database
Manag
Optional supported hypervisors Citrix® XenServer, VMware vSphere® ESXi®, Red Hat® Enterprise Virtualization®
Operating systems Microsoft Windows Server® 2008 R2
Microsoft Windows Server 2012
Microsoft Windows Server 2012 R2
Novell® SUSE® Linux Enterprise Server
Red Hat Enterprise Linux
VMware vSphere ESXi
Rack support ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm.

Dell PowerEdge R430 Review

Dell EMC PowerEdge R430 is an entry-level two-processor server mounted in a 19″ cabinet or rack. Dimensions: small height — 1U, small depth — 24 inch. Perfect solution for companies with limited equipment space. R430 high density makes it perfect for a wide variety of tasks which require high computing powers, storage, scalability, and other resources. The server is an ideal solution for high performance computing (HPC), web-technologies and IT-infrastructure scaling.

dell poweredge r430

Scaleability

Dell R430 is an entry-level server for small companies, offices and branches to use enterprise-level technologies. To make R430 highly effective, yet compact solution, Dell Technologies engineers gave it the following characteristics:

  • Support of two Intel Xeon E5-2600 v3 or v4 (up to 22 cores) processors,
  • Up to 12 DDR4 slots, RDIMM and LRDIMM support, up to 2400 MT/s, up to 256 GB with one processor and up to 384 GB with two processors,
  • Support of PCIe 3.0 standard with ability to scale it to 2 × PCIe 3.0,
  • Support of various network parameters:
    • 2 RJ-45 × 1 Gbps — standard,
    • 2 RJ-45 × 1 Gbps — option,
    • 2 RJ-45 × 10 Gbps — option,
    • 2 SFP+ × 10 Gbps — option.
  • Hot-swappable disks and various bins:
    • Up to 10 × 2.5 SAS/SATA with ability to install 4NVMe,
    • Up to 8 × 2.5 SAS/SATA,
    • Up to 4 × 3.5 SAS/SATA.
  • S130 software controller and RAID hardware controller support: PERC H330, PERC H730, PERC H730P, and PERC H830 main bus front end adapter,
  • Hot-swappable supply units: 450W, 550W PSU.
dell poweredge r430

Control and automation

Dell R430 supports iDRAC 8 Basic out-of-the-box technology: it is a proprietary implementation of IPMI 2.0 protocol to control the server as if it is right in front of you. Fee-based Enterprise and Express level license includes additional functionality.

Dell OpenManage to easily control equipment and automate routine processes.

OpenManage Essentials to save system administrators' time spent on implementation, update, monitoring and maintenance of IT infrastructure. You can centralize control and decrease labour payment expenses.

IDRAC Quick Sync technology with wireless NFC module and OpenManage Mobile app to get important notifications and monitor and control the server using your smartphone.

dell poweredge r430

Security

Dell R430 is based on Dell Technologies cybersecure architecture. The server receives firmware updates and security patches during its whole lifecycle. That's why your system administrator can reliably implement critical business processes and cybersecure them.

  • Secure logistics ensure that the server will travel from the manufacturing plant to the end-client safely,
  • Motherboard cryptographic signature ensures your data is secure,
  • Cryptoprocessor (TPM 2.0) installed in a motherboard chipset is available as an option,
  • System Erase function to remove all data (including cache and logs) from any drives (HDD, SSD, system memory) remotely, quickly, and securely. Thanks to that, you can reset the server to factory settings, dispose it or sell it on the secondary market without any risks of confidential data leak,
  • Software and hardware RAID controllers.

FAQ

What is included in the 5-year warranty for the DELL PowerEdge R430 Server?

    The Servermall warranty includes:

  • Access on a 24x7 basis (including holidays) to the Servermall Customer Service and Support organization for troubleshooting assistance of Servermall Refurbished Servers and Associated Goods and select software issues.
  • 5 year warranty. In case of problem diagnostics or repair, we will do on the server installation site. For free.
  • On-site dispatch of replacement parts to the Installation Site or other mutually agreed upon Customer’s business location approved by Servermall to address a Product problem.

More about the warranty

How to get a discount on the DELL PowerEdge R430 Server?

Subscribe to our news and get a 50€ discount on the server.

Subscribe to the news

What are the terms of delivery of the DELL PowerEdge R430 Server?

Free shipping across EU if ordering equipment from 500€. Delivery from 4 working days.

01

Offer
in one hour

Usually, it would take us 20–30 minutes. Yes, we are that quick.

02

Free shipping
across EU

Once again, we'll be quick. Besides, we'll deliver the equipment to any city.

03

Onsite
diagnostics

In any warranty case, we'll promptly repair or replace the failed equipment. Onsite. For free. For 5 years.

04

Our
warehouse

We own a warehouse in Vilnius: it helps us quickly ship the equipment across Europe.

05

We stick with
our clients

We'll always provide you with after-sales support. Our experts will help you solve any problem.


5

5 YEARS PART
WARRANTY

What? 5 years warranty for refurbished equipment? Sounds crazy, right? In fact, it's not: we are confident in the results of our diagnostics and testing. And if something goes wrong, we'll fix it. For free.

Our features
Complete testing
We want to make sure that our equipment is fully reliable for you. That's why all our equipment (even new) is subject to complete diagnostics, testing, and part replacement.
Our features
Extreme testing
We fully load our equipment with various utilities and software. Rest assured, it'll work for a very long time.
Our features
CPU, RAM, POWER SUPPLY
The components work at full capacity and are tested for several days. If we are not sure about something, we replace it.
Our features
Full testing of all equipment
Our regulations imply the same testing for both used and new equipment. Oh, and by the way, we complement the official manufacturer's warranty with our own warranty.
