| Form factor | 1U rack server |
| Dimensions |
24 x 1.8" and 10 x 2.5" drive configuration: H: 4.28 cm (1.68 in), W: 48.23 cm (18.98 in), D: 75.51 cm (29.72 in) 8 x 2.5" drive configuration: H: 4.28 cm (1.68 in), W: 48.23 cm (18.98 in), D: 70.05 cm (27.57 in) |
| Processor | Intel® Xeon® processor E5-2600 v4 product family |
| Processor sockets | 2 |
| Cache | 2.5MB per core; core options: 4, 6, 8, 10, 12, 16, 18, 22 |
| Chipset | Intel C610 series chipset |
| Memory | Up to 1.5TB (24 DIMM slots): 4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s |
| I/O slots | Up to 3 x PCIe 3.0 slots plus dedicated PERC slot |
| RAID controllers |
Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P External HBAs (RAID): PERC H830 External HBAs (non-RAID): 12Gbps SAS HBA |
| Drive bays |
Internal hard drive bay and hot-plug backplane: Up to 24 x 1.8" SATA SSD Up to 10 x 2.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, Up to 4 NVMe PCIe Up to 8 x 2.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA |
| Maximum internal storage |
HDD: SAS, SATA, nearline SAS SSD: SAS, SATA, NVMe PCIe 24 x 1.8" SSD – up to 23TB via 0.96 TB hot-plug SATA SSD 10 x 2.5" – up to 18TB via 1.8TB hot-plug SAS HDD 8 x 2.5" – up to 14TB via 1.8TB hot-plug SAS HDD |
| Embedded NIC | 4 x 1Gb, 2 x 1Gb + 2 x 10Gb, 4 x 10Gb |
| Power supplies | Titanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W, 1100W |
| Availability |
ECC memory, hot-plug hard drives, hot-plug redundant cooling, hot-plug redundant power, internal dual SD module, single device data correction (SDDC), spare rank, support for high availability clustering and virtualization, proactive systems management alerts |
| Systems management |
Systems management: IPMI 2.0 compliant; Dell OpenManage Essentials; Dell OpenManage Mobile; Dell OpenManage Power Center Remote management: iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade) iDRAC Quick Sync Dell OpenManage Integrations: • Dell OpenManage Integration Suite for Microsoft® System Center • Dell OpenManage Integration for VMware® vCenter™ Dell OpenManage Connections: • HP Operations Manager, IBM Tivoli® Netcool® and CA Network and Systems Management • Dell OpenManage Plug-in for Oracle® Database Manager |
| Rack support | ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm. |
| Operating systems |
Microsoft Windows Server® 2008/2012 SP2, x86/x64 (x64 includes Hyper-V®) Microsoft Windows Server 2008/2012 R2, x64 (includes Hyper-V) Novell® SUSE® Linux Enterprise Server Red Hat® Enterprise Linux Optional embedded hypervisors: Citrix® XenServer® VMware vSphere® ESXi™ |
Dell EMC PowerEdge R630 is a two-processor server mounted in a 19″ cabinet or rack. R630 is the first Dell Technologies 1U server with 2U computation capabilities. Its high density makes R630 perfect for a wide variety of tasks which require high computing powers, storage, scalability, and other resources. Thanks to R360 functionality, you can build virtualization environments, resource-intensive business applications, and databases.
Scaleability
Dell R630 is general-purpose server with flexible configurations and parameters. To make R360 highly effective solution, Dell Technologies engineers gave it the following characteristics:
Dell R630 supports iDRAC 8 Express out-of-the-box technology: it is a proprietary implementation of IPMI 2.0 protocol to control the server as if it is right in front of you. Express level license is part of rack-mounted server, tower server and modular 600-series (and above) system scope of supply. Fee-based Enterprise license includes additional functionality.
Dell OpenManage to easily control equipment and automate routine processes.
OpenManage Essentials to save system administrators' time spent on implementation, update, monitoring and maintenance of IT infrastructure. You can centralize control and decrease labour payment expenses.
IDRAC Quick Sync technology with wireless NFC module and OpenManage Mobile app to get important notifications and monitor and control the server using your smartphone.
Dell R630 is based on Dell Technologies cybersecure architecture. The server receives firmware updates and security patches during its whole lifecycle. That's why your system administrator can reliably implement critical business processes and cybersecure them.
What is included in the 5-year warranty for the DELL PowerEdge™ R630 1U Server?
The Servermall warranty includes:
How to get a discount on the DELL PowerEdge™ R630 1U Server?
Subscribe to our news and get a 50€ discount on the server.
What are the terms of delivery of the DELL PowerEdge™ R630 1U Server?
Free shipping across EU if ordering equipment from 500€. Delivery from 4 working days.
For people, not for show.
Without trifles like paid delivery etc.
A warranty too huge for refurbished equipment? You might have thought we are crazy. We are not. We are just confident in our diagnostics and testing of equipment. In case something goes wrong: we will fix it. For free.
