Form factor |
2U rack |
|
Dimensions |
H: 8.73 cm (3.44 in), W: 44.40 cm (17.49 in), D: 68.40 cm (26.92 in) |
|
Processor |
Intel® Xeon® processor E5-2600 v4 product family |
|
Processor sockets |
2 |
|
Cache |
2.5MB per core; core options: 4, 6, 8, 10, 12, 14, 16, 18, 22 |
|
Chipset |
Intel C610 series chipset |
|
Memory |
Up to 3TB (24 DIMM slots): 4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s |
|
I/O slots |
Up to 7 x PCIe 3.0 plus dedicated PERC slot |
|
RAID controllers |
Internal controllers: PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P
External HBAs (RAID): PERC H830
External HBAs (non-RAID): 12Gbps SAS HBA |
|
Drive bays |
Internal hard drive bay and hot-plug backplane:
Up to 16 x 2.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
Up to 8 x 3.5" HDD: SAS, SATA, nearline SAS SSD: SAS, SATA |
|
Maximum internal storage |
HDD: SAS, SATA, nearline SAS SSD: SAS, SATA
16 x 2.5" – up to 29TB via 1.8TB hot-plug SAS hard drives
8 x 3.5" – up to 64TB via 8TB hot-plug NL SAS hard drives |
|
Embedded NIC |
4 x 1GbE, 2 x 10+2GbE, 4 x 10GbE NDC |
|
Power supplies |
Titanium efficiency 750W AC power supply; 1100W DC power supply; Platinum efficiency 495W, 750W,
1100W AC power supply; |
|
Availability |
ECC memory, hot-plug hard drives, hot-plug redundant cooling, hot-plug redundant power, internal dual SD module, single
device data correction (SDDC), spare rank, tool-less chassis, support for high availability clustering and virtualization,
proactive systems management alerts, iDRAC8 with Lifecycle Controller |
|
Remote management |
iDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade)
8GB vFlash media (upgrade), 16GB vFlash media (upgrade) |
|
Systems management |
IPMI 2.0 compliant
Dell OpenManage Essentials
Dell OpenManage Mobile
Dell OpenManage Power Center
Dell OpenManage Integrations:
• Dell OpenManage Integration Suite for Microsoft®
System Center
• Dell OpenManage Integration for VMware®
vCenter™
Dell OpenManage Connections:
• HP Operations Manager, IBM Tivoli® Netcool®
and CA Network and Systems Management
• Dell OpenManage Plug-in for Oracle® Database
Manager |
|
Rack support |
ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled
mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm. |
|
Operating systems |
Microsoft Windows Server® 2008/2012 SP2, x86/x64
(x64 includes Hyper-V®)
Microsoft Windows Server 2008/2012 R2, x64 (includes
Hyper-V)
Microsoft Windows HPC Server 2008
Novell® SUSE® Linux Enterprise Server
Red Hat® Enterprise Linux
Optional embedded hypervisors:
Citrix® XenServer®
VMware vSphere® ESXi™ |
