Drive description |
10 SFF SAS/SATA/SSD
8 SFF SAS/SATA/SSD or
4 LFF SAS/SATA/SSD |
|
Supported drives |
Hot plug SFF 2.5-inch SAS
Hot plug SFF 2.5-inch SATA
Hot plug SFF 2.5-inch SSD
Hot plug LFF 3.5-inch SAS
Hot plug LFF 3.5-inch SATA
Hot plug LFF 3.5-inch SSD |
|
Processor family |
Intel Xeon E5-2600 v2 or E5-2600 family |
|
Cache |
30 MB L3
25 MB L3
20 MB L3
15 MB L3
10 MB L3
5 MB L3
Depending on processor installed |
|
Processor quantity |
1 or 2 |
|
Processor core available |
12, 10, 8, 6, 4, or 2 |
|
Processor speed |
1.7 to 3.5 GHz |
|
Memory slots |
24 DIMMs, with 4 channels |
|
Maximum memory |
768 GB maximum (256 GB maximum capacity/maximum speed @ 1866 MHz) |
|
Memory type |
DDR3 RDIMM, LRDIMM or UDIMM, HP SmartMemory |
|
Memory protection features |
Advanced ECC, online spare, memory lock-step mode |
|
Network controller |
HP FlexibleLOM 1Gb 331FLR Ethernet adapter on some models, and HP FlexibleLOM 10Gb 2-port 530FLR-SFP+ Ethernet
Adapter on others; Options: 4-ports or 2-ports 10 GB, CNA, SFP+, FCoE, and InfiniBand solutions |
|
Storage controllers |
Smart Array P420i controller (optional flash back write cache [FBWC] 512 MB, 1 G, 2 G) |
|
Internal storage |
SATA, SAS, SSD
(10 or 8) 2.5" hot plug bays optional (4) 3.5" hot-plug bays
Includes bay for optional optical drive |
|
Maximum internal storage |
12 TB SFF (10 x 1.2 TB HDD) or
9.6 TB SFF (8 x 1.2 TB HDD) or
12 TB LFF (4 x 3 TB HDD) |
|
Expansion slots |
2x PCIe 3.0 slots for x16-FHHL, and x8 low profile option cards maximum, with HP exclusive tool-less quick access feature |
|
Remote management software |
HP iLO Management Engine |
|
Form factor chassis |
Rack |
|
System fans features |
Hot plug fully redundant |
|
Power supply type |
Hot plug redundant power supply |
|
Graphic card |
FHHL PCIe 3.0 slot for standard graphics cards up to 75 W |
|
Memory protection features |
Advanced ECC, online spare, memory lock-step mode |
|
Full configuration form factor |
1U |
|
Supported operating systems |
- Microsoft® Windows® Server Editions
- Linux (Red Hat, SUSE, and United)
- Oracle Solaris
- VMware/XenSource/RH and SLES Xen/Microsoft Hyper-V
|
|
Warranty (Parts/labor/onsite) |
Three-year parts, three-year labor, three-year onsite |
