HPE ProLiant DL20 Gen10 Plus 4SFF
You might be interested in
- Processor
- Processor number: 1
Processor core available: 4 to 8 core, depending on processor
Processor cache: Up to 16 MB Intel® Smart Cache, depending on processor
Processor speed: 5.0 GHz, maximum depending on processor - Memory
- Maximum memory: 128 GB
Memory slots: 4 DIMM slots, maximum
Memory type: HPE DDR4 Standard Memory
Memory protection features: ECC - Drive supported
- 2 Non-hot plug LFF or 2 Hot plug LFF or 4+2 Hot plug SFF
- Infrastructure management
- HPE iLO5
- Power supply type
- 290W non-hot-plug power supply with Platinum power efficiency.
- Expansion slots
- Two maximum
- Network controller
- HPE embedded 1Gb 2-port BCM5720 Network Adapter
- Storage controller
- Intel® VROC SATA (formerly known as Intel® RSTe)
- Form factor
- 1U
- Technical Specifications
- SFF Drives
4.32 x 43.46 x 38.22 cm
LFF Drives 4.32 x 43.46 x 38.22 cm
Weight 6.00 - 10 kg - Condition
- Refurbished
- Manufacturer
- HPE
- Form factor
- 1U
- Remote-Control-Modul
- iLO 5
- Supported CPU
- 1 x Intel Xeon E-2300 or Pentium
- Supported RAM
- DDR4 DIMM 4 slots (128 GB)
- Power supply unit
- Power supply HP 800w
- RAID controller
- RAID Embedded Intel VROC SATA SW
- HDD bays
- noHDD (up to 4 HDD 2.5'' SFF)
Need a technical consultation on choosing a server?
Submit a requestHPE ProLiant DL20 Gen10 Plus 4SFF is a compact 1U rack server storage configuration with four front hot-plug Small Form Factor drive bays. It is designed for small businesses, branch offices, edge locations, and space-constrained IT environments that require serviceable local storage and enterprise-class management.
Key features:
-
4 SFF hot-plug drive bays: Provides four front-accessible 2.5-inch SFF hot-plug bays in a compact 1U chassis, allowing supported drives to be serviced without opening the server.
-
SAS and SATA drive support: The 4SFF cage can be configured with supported SAS or SATA HDDs and SSDs. SAS support and advanced RAID functions require an appropriate HPE Smart Array controller, while the embedded Intel VROC storage path is SATA-only.
-
Optional 4+2 SFF expansion: An optional two-bay SFF enablement kit can increase the front drive count from four to six SFF bays in supported configurations.
-
Flexible RAID configuration: Embedded Intel VROC SATA software RAID provides an entry storage path, while supported HPE Smart Array controllers add hardware RAID, cache, and broader enterprise drive support.
-
Compact enterprise platform: Intel Xeon E or Intel Pentium processor options, PCIe Gen4 expansion, HPE iLO 5, and front hot-plug access make the server suitable for distributed business infrastructure.
Use cases:
-
Branch office services: Suitable for local file, print, directory, security, and infrastructure services at remote or distributed sites.
-
Small business applications: Provides reliable local storage for collaboration tools, line-of-business applications, and lightweight databases.
-
Edge and space-constrained deployments: The compact 1U form factor is practical for retail locations, telecom rooms, and smaller server racks.
-
Local backup and management workloads: Can be used for backup staging, monitoring, logging, and other operational services that benefit from hot-plug SFF storage.
HPE ProLiant DL20 Gen10 Plus 4SFF is a practical entry enterprise configuration for organizations that need compact 1U deployment, four serviceable SFF bays, and a clear path from embedded SATA RAID to HPE Smart Array storage.
