DELL PowerEdge T560 Server
You might be interested in
Free shipping across the EU for orders over 500 € Contact manager
5-year warranty on servers and storage systems
Up to 70% reduction in IT infrastructure CAPEX
Wide range of equipment in stock
T560
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
-
Condition
Refurbished
-
CPU
2×8GB DDR4 RDIMM 2133MHz
-
RAM
noHDD (up to 8 HDD 2.5'' SFF)
Total price
Can’t find the parts you need? We’ll find a solution
This is not a quote. Final price depends on configuration and current market conditions. Check up-to-date prices with our manager
Dell T560 8LFF
Condition
New
Allocate VAT
Free shipping across the EU for orders over 500 € Contact manager
5-year warranty on servers and storage systems
Work for you since 2018
Up to 70% reduction in IT infrastructure CAPEX
Wide range of equipment in stock
DELL T560 Technical specifications
- Processor
- Up to two 4th Generation Intel® Xeon Scalable processor, with up to 32 cores per processor
Up to two 5th Generation Intel® Xeon Scalable processor, with up to 28 cores per processor - Memory
- 16 DDR5 DIMM slots, supports RDIMM 1.5 TB max
- Speeds up to 4800 MT/s on the 4th Generation Intel® Xeon Scalable processor
- Speeds up to 5200 MT/s on the 5th Generation Intel® Xeon Scalable processor
- Supports registered ECC DDR5 DIMMs only
- Storage controllers
- Internal PERC: fPERC H965i, fPERC H755N, fPERC H755, fPERC H355, fPERC HBA355i, HBA465i fPERC
- Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSD drives, or USB
- External HBA (non-RAID): PERC HBA355e
- Software RAID: S160 (for NVMe drives only)
- Drive Bays
- Front bays:
- Up to 12 x 3.5-inch SAS/SATA HDD drives, max 180 TB
- Up to 8 x 3.5-inch SAS/SATA HDD drives, max 120 TB
- Up to 8 x 3.5-inch SAS/ SATA HDD + 8 x 2.5-inch NVMe SSD drives, max 240 TB
- Up to 8 x 2.5-inch SAS/SATA HDD drives, max 120 TB
- Up to 16 x 2.5-inch SAS/SATA HDD drives, max 240 TB
- Up to 24 x 2.5-inch SAS/SATA HDD drives, max 360 TB
- Power Supplies
- 600 W Platinum 100-240 VAC/240 VDC
- 700 W Titanium 200-240 VAC/240 VDC
- 800 W Platinum 100-240 VAC/240 VDC
- 1100 W Titanium 100-240 VAC/240 VDC
- 1100 W DC/-48-(-60) V
- 1400 W Platinum 100-240 VAC/240 VDC
- 1400 W Titanium 100-240 VAC/240 VDC
- 1400 W Titanium 277 VAC/336 VDC
- 1800 W Titanium 200-240 VAC/240 VDC
- 2400 W Platinum 100-240 VAC/240 VDC
- 2800 W Titanium 200-240 VAC/240 VDC
- Cooling Options
- Air cooling
- Fans
- Up to eight Standard (STD) fans or High performance (HPR) fans
- Dimensions
- Height — 464.0 mm (18.26 inches) (with feet)
- 508.8 mm (20.03 inches) (with caster wheels)
- 446.0 mm (17.60 inches) (without feet) - Width — 200.0 mm (7.87 inches)
- Depth — 678.2 mm (26.70 inches) (with bezel)
- 660.6 mm (26 inches) (without bezel)
- Height — 464.0 mm (18.26 inches) (with feet)
- Weight
- 12 x 3.5-inch (SAS/SATA) - 48 kg (107.32 pound)
- 8 x 3.5-inch (SAS/SATA) - 43.16 kg (95.15 pound)
- 8 x 3.5-inch (SAS/SATA) + 8 x 2.5-inch NVMe - 46.84 kg (103.26 pound)
- 8 x 2.5-inch (SAS/SATA) - 39.40 kg (86.86 pound)
- 16 x 2.5-inch (SAS/SATA) - 42.02 kg (92.63 pound)
- 24 x 2.5-inch (SAS/SATA) - 44.64 kg (98.41 pound)
- Form Factor
- 4.5U tower server
- Embedded Management
- iDRAC9
- iDRAC Direct
- iDRAC RESTful API with Redfish
- iDRAC Service Module
- Quick Sync 2 wireless module
- Bezel
- Optional security bezel
- OpenManage Software
- OpenManage Enterprise
- OpenManage Power Manager plugin
- OpenManage Service plugin
- OpenManage Update Manager plugin
- CloudIQ for PowerEdge plug in
- OpenManage Enterprise Integration for VMware vCenter
- OpenManage Integration for Microsoft System Center
- OpenManage Integration with Windows Admin Center
- Mobility
- OpenManage Mobile
- OpenManage Integrations
- BMC Truesight
- Microsoft System Center
- OpenManage Integration with ServiceNow
- Red Hat Ansible Modules
- Terraform Providers
- VMware vCenter and vRealize Operations Manage
- Security
- Cryptographically signed firmware
- Data at Rest Encryption (SEDs with local or external key mgmt)
- Secure Boot
- Secure Erase
- Secured Component Verification (Hardware integrity check)
- Silicon Root of Trust
- System Lockdown (requires iDRAC9 Enterprise or Datacenter)
- TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
- Embedded NIC
- 2 x 1GbE LOM on Planar
- Network Options
- 1 x OCP x8 card 3.0
Note: The system allows both LOM on planar and OCP card to be installed on the system. - GPU Options
- Up to 2 x 300 W DW or 6 x 75 W SW
- Ports
- Front Ports:
- 1 x USB 2.0
- 1 x USB 3.0
- 1 x iDRAC Direct (Micro-AB USB) port
- 1 x USB 2.0
- 1 x USB 3.0
- 1 x Serial port (optional)
- 1 x Dedicated iDRAC (RJ45) port
- 1 x VGA port
- 2 x Ethernet ports
- 1 x USB 3.0 (optional)
- PCIe
- Up to six PCIe slots:
- Slot 1: x16 Gen5 Full height, Full length
- Slot 2: x16 Gen5 Full height, Full length
- Slot 3: x16 Gen4 Full height, Half length
- Slot 4: x16 Gen4 Full height, Half length
- Slot 5: x16 (x8 lanes) Gen4 Full height, Half length
- Slot 6: x16 Gen4 Full height, Half length
- Operating System and Hypervisors
- Canonical Ubuntu Server LTS
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linu
- SUSE Linux Enterprise Server
- VMware ESXi
